Solar Module Production Line

Overview

Layout


Typical Layout of Solar Panel Module PV Photovoltaic Production Line
  1. Solar Cell Laser Scribing & Cutting Machine
  2. Solar Cell Sorting Machine
  3. Solar Cell Storage Cart
  4. Single & Serial Solar Cell Assembly & Soldering Table
  5. Serial Solar Cell Storage Cart
  6. Glass Vertical Storage Cart
  7. Solar Module Assembly & Pre-Inspection Table
  8. EVA TPT Storage Cart
  1. Inspection Rack
  2. Ribbon & Busbar Cutting Machine
  3. Ribbon & Busbar Drying Machine
  4. EVA TPT Cutting Table
  5. Solar Module Horizontal Storage Cart
  6. Vacuum, Heating & Laminating Machine
  7. Trimming & Inspecting Table
  8. Solar Module Vertical Storage Cart
  1. Aluminum Profile Sealing Machine
  2. Aluminum Profile Storage Cart
  3. Aluminum Frame Installing Machine
  4. Inspection Table
  5. Junction Box Assembly Table
  6. Final Inspection Device
  7. Packing Table
