Vertical Straight Line Glass Profile Edging Machine

Features

G-VPB-611

Highlights

PLC with HMI Touch Panel Operator Interface of G-VPE-611 Vertical Glass Profile Edging Machine Processes Pencil Edges
  • 8 spindles G-VPB-611 glass round edging machine produces round edge, OG edge, waterfall & other profile edges
  • PLC with HMI touch panel operator interface regulates glass thickness
  • Glass working speed adjustable by frequency converter
  • Bearing transmission main conveying mechanism
  • First two 45o cup wheels remove glass arris heavily reducing subsequent wheels workloads
  • Grinding speed is increased while peripheral wheels last longer
  • Three polishing wheels obtain fine bright edges
  • Pneumatic polishing wheels controlled by PLC
  • Mechanical diamond wheel spindles with locking systems
  • Up to 700 kg glass loading
  • Heavy duty structure weighs 4500 kg

Wheels Configuration

#8BK90 Peripheral Wheel for Glass Profile Fine Polishing #7BK60 Peripheral Wheel for Glass Profile Polishing #6BK40 Peripheral Wheel for Glass Profile Polishing #5Resin Bond Diamond Peripheral Wheel for Glass Profile Fine Grinding #4Resin Bond Diamond Peripheral Wheel for Glass Profile Fine Grinding #3Metal Bond Diamond Peripheral Wheel for Coarse Glass Profile Grinding #2Metal Bond Diamond Cup Wheel for Coarse Front Seam Grinding #1Metal Bond Diamond Cup Wheel for Coarse Rear Seam Grinding Positions
Peripheral Peripheral Peripheral Peripheral Peripheral Peripheral Cup Cup Forms
CE3 BK60 BK46 Resin Diamond Resin Diamond Metal Diamond Metal Diamond Metal Diamond Materials
Polishing Polishing Polishing Fine Grinding Coarse Grinding Coarse Grinding Coarse Seam Grinding Coarse Seam Grinding Applications
Φ150 Φ150 Φ150 Φ150 Φ150 Φ150 Φ130 Φ130 OD Sizes (mm)
Φ70 Φ70 Φ70 Φ70 Φ70 Φ70 Φ22 Φ22 ID
NA NA NA #320 #230 #140 #100 #100 Grit
AC 1.5 AC 2.2 AC 2.2 AC 2.2 AC 2.2 AC 2.2 AC 2.2 AC 2.2 Motors Power (kW)
Pneumatic Pneumatic Pneumatic Mechanical Mechanical Mechanical Mechanical Mechanical Wheels Spindles Feeding
