Glass Manipulators

Specifications

MPL-M-B

MPL-M-B Trolley Type Glass Lifting and Tilting Manipulator Diagram
Models MPL-M-B
Max. Glass Loading 200 kg
Suction Cups 4
Max. Lifting Height 1800 mm when Glass is Horizontal
90o Tilting Electrical Driven
Charging Voltage AC 220V / AC 110V
Voltage DC 12 V
Outer Dimensions (Lx W x H) 1500 x 1100 x 2550 mm
