Glass Handling & Transfering Tables & Conveyors

Features & Specs

Air Floatation Table with Tilting Arms

Strong Glass Tilting Arms of Steady Felt Table Activated by Robust Cylinders
  • Series GH-FT-B is Made of Sturdy Welded Tubular Steel Structure Painted with Top Quality Varnish
  • Strong Tilting Arms Activated by Robust Cylinders
  • Shock Free Tilting Arms Motions Especially When Approaching Horizontal Position
  • Compact Air Blower Beneath Table
  • Powerful Air Floatation Allowing Glass Moved Freely on Table
  • Distortion Free Table Top
  • Table Top Covered by Non Scratch Durable Thick Felt
  • Standard Tables Comes Without Break Out Bars
  • Standard Tables Comes With Tilting Arms on Long Edge
Models GH-FT-B-1020 GH-FT-B-1525 GH-FT-B-2030 GH-FT-B-2537 GH-FT-B-3361
Max. Glass Size (mm) 1000 x 2000 1500 x 2500 2000 x 3000 2500 x 3700 3300 x 6100
Working Height(mm) 900 900 900 900 900
Max. Glass Loading (kg) 100 160 300 400 900
Tilting By Pneumatic Pneumatic Hydraulic Hydraulic Hydraulic
Compress Air Consumption (Lt/min.) 180 200 250 300 400
Compress Air Pressure (MPa) 0.5 ~ 0.8 0.5 ~ 0.8 0.5 ~ 0.8 0.5 ~ 0.8 0.5 ~ 0.8
Power (KW) 1.5 2 4 5.1 11.5
Weight (kg) 200 300 600 900 2000
Outer Dimensions (LxWxH) (m) 2.1 x 1 x 0.9 2.6 x 1.5 x 0.9 3.1 x 2 x 0.9 3.7 x 2.5 x 0.9 3.3 x 6.1 x 0.9
