Features & Specs
Continuous Belt Conveying Fusing Glass Kiln (GFKF-CT-A)
- Continuous Glass Fusing Kiln
- Electric Motorized Belt Conveying Design
- Metal Structure Painted With High Temperature Resistant Varnish
- Well Heat Preservation Thermal Insulation
- PLC Temperature Control
- Automatic Production Process From Heating, Fusing, Annealing Till Cooling
- Low Power Consumption While High Production Efficient
| Models | GFKF-CT-A-0826 | GFKF-CT-A-1026 | GFKF-CT-A-1032 | GFKF-CT-A-1040 |
| Interior Width | 800 mm | 1000 mm | 1000 mm | 1000 mm |
| Interior Length | 26 m | 26 m | 32 m | 40 m |
| Interior Height | 380 mm | 380 mm | 380 mm | 380 mm |
| Install Power | 95 KW | 130 KW | 145 KW | 175 KW |
| Voltage | 380 V / 3 phase / 50 Hz | |||
| Outer Dimensions (L x W x H) |
30 x 1 x 1.2 m | 30 x 1.4 x 1.2 m | 36 x 1.4 x 1.2 m | 44 x 1.4 x 1.2 m |
