Portable Glass Hole Drilling Machine
Overview
Features & Specs
Features & Specs
Models
GHD-P-A
GHD-P-B
GHD-P-C
GHD-P-D
Nr. Of Drilling Spindles
Single (Top Spindle)
Single (Top Spindle)
Single (Top Spindle)
Single (Top Spindle)
Max. Drilling Diameter
Φ 100 mm
Φ 100 mm
Φ 250 mm
Φ 250 mm
Spindle Rotation Speed
1400 RPM
1400 RPM
1400 RPM
1400 RPM
Glass Core Drilling Bit
L75, G1/2
L75, G1/2
L75, G1/2
L75, G1/2
Power
0.15 KW
2 KW
0.18 KW
0.18 KW
Voltage
220V / 50Hz
220V / 50Hz
220V / 50Hz
220V / 50Hz
Weight
8 kg
14 kg
12 kg
12 kg
Outer Dimension (W x L x H)
280 x 100 x 300 mm
280 x 200 x 400 mm
220 x 200 x 400 mm
380 x 360 x 590 mm
