GBO-C Continuous Glass Bending Ovens

Introduction

Continuous Glass Bending Furnace

Series GBO-C continuous glass bending ovens is used to bend small medium size of glass. Glass runs continuously from entrance till exit at the other end passing through pre-heating, bending, annealing and cooling sections. This oven is also very suitable for glass bake, glass cook, glass decorating and glass fusing.

Structure

Oven Body

It is a metal structure painted with high temperature resistant varnish. Oven walls are insulated with thermal preservation materials.

Heating System

There are heating resistors distributed at top of oven in pre-heating, bending and annealing sections. There are thermocouples measuring real time temperatures.

Conveying System

Belt conveyor runs from oven entrance till exit at the other end of oven.

Driving Mechanism

Belt conveyor is driven by powerful electrical motor adjusted by speed regulator.

Control System

It is a standalone electrical control console. It controls heating profile and belt conveyor speed.

Specifications

Models GBO-C-0826 GBO-C-1026 GBO-C-1032 GBO-C-1040
Oven Interior Width 800 mm 1000 mm 1000 mm 1000 mm
Oven Interior Length 26 m 26 m 32 m 40 m
Oven Interior Height 380 mm 380 mm 380 mm 380 mm
Install Power 95 KW 130 KW 145 KW 175 KW
Voltage 380 V / 3 phase / 50 Hz
Outer Dimensions (LxWxH) 30 x 1 x 1.2 m 30 x 1.4 x 1.2 m 36 x 1.4 x 1.2 m 44 x 1.4 x 1.2 m
